Capacity 8 – 50 mm
8 – 40 mm
Blade Motor 10 HP
Hydraulic Pump Motor 2 HP
Blade Speed 55 - 220 rpm
Saw Blade Size
(T: kerf   t: thickness)
Ø 250 x T2.0 x 1.75t mm
Bar Feed Servo motor and ball screw
Blade Feed Servo motor and ball screw
Automatic Feed Length Single feed 6 – 400 mm
Multiple feed – 3000 mm
Automatic Chip Conveyor Hydraulic spiral type
Cooling Air compressed oil mist
Machine Weight with Table Approx. 1900 kgs
Machine Dimension 1900 (W) x1500 (L) mm

* All specifications, dimensions and design characteristics shown in this catalogue are subject to change without prior notice.
